LAND ROVER DEFENDER ESTATE

Emissions - ICE

• HC+NOx
  Not Available
• Particles
  Not Available
• Standard Emissions
  EURO 6
• WLTP - CO2 (g/km) - Comb
  320
• WLTP - CO2 (g/km) - Comb - TEH
  329
• WLTP - CO2 (g/km) - Comb - TEL
  320

Engine and Drive Train

• Camshaft
  DOHC
• Catalytic Convertor
  Yes
• CC
  5000
• Compression Ratio
  9.5:1
• Cylinder Layout
  V8
• Cylinders
  8
• Cylinders - Bore (mm)
  92.5
• Cylinders - Stroke (mm)
  93
• Engine Layout
  NORTH SOUTH
• Fuel Delivery
  SUPERCHARGER
• Gears
  8 SPEED
• Number of Valves
  32
• Transmission
  AUTO

Fuel Consumption - ICE

• EC Directive 1999/100/EC Applies
  No
• WLTP - FC (l/100km) - Comb
  14.2
• WLTP - FC (l/100km) - Comb - TEH
  14.6
• WLTP - FC (l/100km) - Comb - TEL
  14
• WLTP - MPG - Comb
  19.9
• WLTP - MPG - Comb - TEH
  19.4
• WLTP - MPG - Comb - TEL
  20.2

General

• Alternative Fuel Qualifying
  No
• Badge Engine CC
  5.0
• Badge Power
  525
• Based On ID
  Not Available
• Coin Description
  P525
• Coin Series
  90
• Generation Mark
  2
• Insurance Group 1 - 50 Effective January 07
  50E
• Manufacturers Corrosion Perforation Guarantee - Years
  6
• Manufacturers Paintwork Guarantee - Years
  3
• NCAP Adult Occupant Protection %
  85
• NCAP Child Occupant Protection %
  85
• NCAP Overall Rating - Effective February 09
  5
• NCAP Pedestrian Protection %
  71
• NCAP Safety Assist %
  79
• Did at least one aspect of this vehicle's safety give cause for concern?
  No
• Service Interval Frequency - Months
  12
• Service Interval Mileage
  16000
• Special Edition
  No
• Special Order
  No
• Standard manufacturers warranty - Mileage
  Unlimited
• Standard manufacturers warranty - Years
  3
• Timing Belt Interval Frequency - Months
  Not Available
• Timing Belt Interval Mileage
  Not Available
• Vehicle Homologation Class
  M1

Performance

• 0 to 62 mph (secs)
  5.2
• Engine Power - BHP
  525
• Engine Power - KW
  386
• Engine Power - RPM
  6500
• Engine Torque - LBS.FT
  461
• Engine Torque - MKG
  63.7
• Engine Torque - NM
  625
• Engine Torque - RPM
  2500
• Top Speed
  149

Test Cycles

• Emissions Test Cycle
  WLTP
• RDE Certification Level
  RDE 2

Tyres

• Alloys?
  Yes
• Space Saver?
  No
• Tyre Size Front
  275/45 R22
• Tyre Size Rear
  275/45 R22
• Tyre Size Spare
  FULL SIZE
• Wheel Style
  5 SPOKE STYLE 5098
• Wheel Type
  22" ALLOY

Vehicle Dimensions

• Height
  1969
• Height (including roof rails)
  Not Available
• Length
  4583
• Wheelbase
  2587
• Width
  2008
• Width (including mirrors)
  2105

Weight and Capacities

• Fuel Tank Capacity (Litres)
  90
• Gross Vehicle Weight
  3040
• Luggage Capacity (Seats Down)
  1263
• Luggage Capacity (Seats Up)
  297
• Max. Loading Weight
  569
• Max. Roof Load
  100
• Max. Towing Weight - Braked
  3500
• Max. Towing Weight - Unbraked
  750
• Minimum Kerbweight
  2471
• No. of Seats
  5
• Turning Circle - Kerb to Kerb
  11.3
